| Model No | JY23ACG | ||
| Reticle Options |  | | |
| 2 MOA Dot | 3 Patterns shift:Circle Dot,Circle,Dot | ||
| Shake Awake Technology | 1. Auto power off in 2 minutes without motion. 2. Power on as soon as motion sensed. | ||
| Illumination Source | ultra-high-power LED emitter | ||
| Objective Lens Dia | 23mm | ||
| Magnification | 1X | ||
| Eye Relief | Unlimited | ||
| Parallex | ≤2MOA | ||
| Height of Optical Axis | 40.4mm | ||
| Click Value | 1 MOA | ||
| Total Elevation Range | 100 MOA | ||
| Total Windage Range | 100 MOA | ||
| Battery | CR2032 | ||
| Battery Life | 50,000h（2moa dot) Multi reticle 10,000h | ||
| Illumination Setting | 8 daytime + 2 NV | ||
| Housing Material | CNC Aluminum Housing, 6061 | ||
| Housing Surface | Anodized | ||
| Dimension (LxWxH) | 52X42.7X69mm( mount included) | ||
| Weight | 135g | ||
| Mount Type | Lower 1//3 Co-witness Mount for Picatinny Rail | ||
